TECHNICAL FEATURES

• Technical features 1st stage • Hyperbalanced diaphragm (watertight chamber on t10-sc) • 2 hp 7/16 unf ports • 4 mp 3/8 unf ports • Operating pressure: 300 bar (4350 psi) din version, 232 bar (3365 psi) international version • Calibration pressure: 10 bar • High-capacity conical filter in chemically nickel-plated spherical bronze • Removable nozzle in aisi 316 steel • Hyperbalancing system • Anti-pressure drop pneumatic spring • Stainless steel calibration spring with micropeening treatment • Low-friction technopolymer slider shaft body protection in polyurethane thermoplastic • Quantity of air supplied: 4500 l/min • Weight, int version: 720 gr • Weight, din version: 602 gr • Technical features 2nd stage • Pneumatically balanced • Adjustable venturi • Adjustable inhalation effort • Patented elliptical diaphragm • Patented low-friction lever • Air delivery system without injector • Adjuster knob with dual or • Internal heat exchanger • Cap opening with cam-lock • Noise-absorbing technopolymer body • Removable technopolymer deflector • Removable mechanics • Weight without hose: 202 gr • Combination performance • Average cracking effort 3.5 mbar average breathing effort 0.6 j/l • Jacketed hose extremely light and flexible weight: 153 gr • Certification en250/2014 for cold water
